Overview

The perfect tool for end face inspection of unmated fiber optic connectors for dirt, end-face quality and patch lead continuity. High quality construction & helpful features will improve the performance of all technical staff in portable or desktop applications. x400 magnification combined with excellent resolving power, is ideal for more intensive single mode and multimode inspection during manufacture, QA, R&D etc.

  • Best image quality & ease of use
  • 400x magnification for singlemode fiber use
  • Optional alternative eyepiece for x200 magnification, option OPT690
  • Greatly improved eye safety: Class 3B laser eye safety
  • Range of fiber connector adapters
  • Easy focus & image centering
  • Long alkaline battery life or external power
  • Video capture option
  • Stabilized illumination with timer
  • Lanyard and tripod mounts
  • Coaxial, oblique or core illumination
  • QA report with ISO 9001 traceable eye safety test

Key Features

Specifications

KI6611 specifications
Optical magnification x400

Resolving power 0.388 µm

Max viewable area diameter 0.5 mm

Country of Origin Australia

Shipping Weight 1500 g

General FiberSafe Microscope KI 6610 Series specifications
Max eye safety input limit (IEC60825-2 Ed.3.1) 20 dBm (@ 635 ~ 800 nm) / 30 dBm (@ 800 ~1650 nm)

Illumination modes Coaxial, oblique, core

Damage level 30 dBm

Power Battery / External power via micro-USB

Battery 1x AAA (LR03) Alkaline

Battery life 300 hours (coaxial illumination for KI6608 & KI6610) / 75 hours (coaxial illumination for KI6611)

Auto off When powered by battery

Size 184.4 mm x 49.3 mm

Unit weight 0.21 kg

Shipping weight 1.5 kg

Illuminating LED's life 100,000 hours

Operating / storage temperature -15 to 55°C / -25 to 70°C

Eyepiece Mount 23.2 mm diameter push-in (standard mount)

Fiber Adaptor Mount 1-1/2" UN 28 TPI 2A Thread

Relative humidity 95%

Warranty 3 years


Documentation & Support

Applications

In the box

Optional accessories

OPT682

1.25 mm Universal Connector Adapter for KI6610 Series Microscope. OPT682

Universal 1.25 mm PC, Simplex / Duplex and terminus for ruggedised connectors

OPT682A

1.25 mm APC Universal Connector Adapter for KI6610 Series Microscope. OPT682A

Universal 1.25 mm, APC, Simplex / Duplex and terminus for ruggedised connectors. For regular use, a connector specific adapter is preferred

OPT672

1.6 mm Terminus Connector Adapter for KI6610 Series Microscope. OPT672

Universal 1.6 mm for ARINC 801 Size 18 Terminus, MIL-DTL-38999 Size 16 Terminus

OPT672A

1.6 mm APC Terminus Connector Adapter for KI6610 Series Microscope. OPT672A

Universal 1.6 mm APC for ARINC 801 Size 18 Terminus, MIL-DTL-38999 Size 16 Terminus

OPT685
OPT685A
OPT683

FMA Adapter Ring for KI6610 Series Microscope. OPT683

Adapter Ring for JDSU FMA series adapters, 7/8" 28 TPI

OPT690

x10 Microscope Eyepiece, OPT690

Optional eyepiece for KI6600 series microscope. Converts KI6610 to x100 magnification, KI6611 to x200 magnification. 23.2 mm scope mounting diameter

OPT155

Semi-Rigid Carry Case for Test Kits OPT155

Semi-rigid canvas test kit case for three KI900 series instruments, optical microscope & VFL pen. With cleaning materials, carry straps and compartments for accessories storage. Moulded interior provides a perfect combination of durability, protection, and comfortable use.

OPT154B

Semi-Rigid Carry Case for Test Kits OPT154B

Semi-rigid canvas test kit case for two KI2000 series instruments, three KI900 series instruments, optical microscope & VFL pen. With cleaning materials, carry straps and compartments for accessories storage. Moulded interior provides a perfect combination of durability, protection, and comfortable use.

TOOL CLEAN-09A

Fiber Connector Cleaner Cartridge TOOL CLEAN-09A

To clean a connector end face / tip, prior to connector insertion into a mating adaptor.

TOOL CLEAN-03

Stick-Type Cleaner 2.5 mm TOOL CLEAN-03

To clean the end face and mating sleeve of a fiber optic connector with 2.5 mm diameter ferrule. SC, FC, ST etc.

TOOL CLEAN-04

Stick-type Cleaner 1.25 mm TOOL CLEAN-04

To clean the end face and mating sleeve of a fiber optic connector with 1.25 mm diameter ferrule, LC, SN etc
