Overview

A family of LED & Laser Light Source test instruments for general purpose loss testing of multimode & single mode systems. Typical applications include fiber optic attenuation measurement, VisiTest, polarity testing and fiber identification on critical systems.

The KI 2400 Series Zero Warm-up Light Source uses an advanced optical stabilization method which avoids the usual laser package-warm up and thermal power drift limitations, to offer ultra high stability, insensitivity to variations in ambient temperature or ORL, and zero warm up time. Typical applications include laboratory-precision loss testing, or in environments with a wide ambient temperature range.

  • Easy to use, rugged & versatile
  • 3 year warranty & calibration cycle
  • Long battery life, micro USB power/charger
  • Alkaline or rechargeable batteries, AA x 2
  • Interchangeable connectors with dust cap & tilt bail
  • Superior re-connection repeatability, < 0.1 dB
  • Excellent stability
  • Unique & useful VisiTest VFL option
  • Autotest & Multi-Fiber ID Tone generator
  • Multimode λ: 850, 1300
  • Single Mode λ: 1310, 1490, 1550, 1625
  • Up to 6 CWDM / DWDM λ please enquire
  • POF λ: 470, 520, 650, 660
  • VFL λ: 635, 650
  • Full QA & test reports ISO/IEC 17025 traceable
  • KI 2419 eLED for ultimate stability or chromatic dispersion testing

MPO Verifier has a different feature set

Part Number Details

Products
Part Number
Description
Suited for
850-1300 nm LED, 1310-1550 nm Laser
Suited for
850-1300 nm LED, 1310-1550 nm Laser APC
Suited for
850-1300 nm LED, 1310-1550 nm Laser VisiTester
Suited for
850-1300 nm LED, 1310-1550 nm Laser VisiTester APC
Suited for
850-1300 nm LED VisiTester, 1310-1550 nm Laser VisiTester
Suited for
850-1300 nm LED, 1310-1550-1625 nm Laser APC
Suited for
1310-1550 nm Ultra Stable, Edge Emitting LED
Suited for
1310-1550 nm Ultra Stable Laser
Suited for
1310-1550 nm Laser
Suited for
1310-1550 nm Laser VisiTester
Suited for
1310-1550 nm High Power +5dBm Laser
Suited for
850-1300 nm LED
Suited for
850-1300 nm LED VisiTester
Suited for
1310-1550-1625 nm Ultra Stable Laser APC
Suited for
1310-1550-1625 nm Laser APC
Suited for
1310-1550-1625 nm Laser VisiTester APC
Suited for
1310-1490-1550-1625 nm Laser APC
Suited for
470-520-660 nm LED for POF/PCS
Suited for
MPO-12 Visual Cable Verifier Source
Suited for
MPO-24 Visual Cable Verifier Source
Suited for
MPO-32 Visual Cable Verifier Source
Suited for
MPO-72 Visual Cable Verifier Source
Suited for
Not sure? Make a general enquiry.

Key Features

Specifications

General Handheld Source KI 2400 & 2800 Series specifications

For more detailed specifications, please select a specific part number from the parts & stock section.

Calibration validity (ISO/IEC 17025) 3 years

Modulated output 270 Hz, 1 kHz, 2 kHz ± 2 %, 12 Multi-Fiber ID tones

Autotest (not available for 470, 540 nm LED sources) Compatible with KI Autotest power meter port & matching λ

Power Battery / External power via micro-USB

Battery types 2x AA (LR6) Alkaline / 2x AA NiMH AA (rechargeable via micro-USB)

Battery life Laser/LED source: 90/80 hours in Autotest, typical

Auto off Selectable

Case Polycarbonate (body) / rubber (edges & corners), moisture resistance, 1-meter drop tested

Size 190 mm x 105 mm x 35 mm

Unit weight 0.42 kg

Shipping weight 1.5 Kg

Operating / storage temperature -15 to 55 °C / -25 to 70 °C

Relative humidity 0 ~ 95 %

Warranty 3 years

IP Rating IP52


Documentation & Support

In the box

Optional accessories

OPT153-CASE

Semi-Rigid Carry Case for Test Kits OPT153-CASE

Semi-rigid canvas test kit case for two KI2000 or KI7000 series instruments, and three KI9000 series instruments. With carry straps and compartments for accessories storage. Moulded interior provides a perfect combination of durability, protection, and comfortable use.

OPT154B

Semi-Rigid Carry Case for Test Kits OPT154B

Semi-rigid canvas test kit case for two KI2000 series instruments, three KI900 series instruments, optical microscope & VFL pen. With cleaning materials, carry straps and compartments for accessories storage. Moulded interior provides a perfect combination of durability, protection, and comfortable use.

TOOL CLEAN-09A

Fiber Connector Cleaner Cartridge TOOL CLEAN-09A

To clean a connector end face / tip, prior to connector insertion into a mating adaptor.

TOOL CLEAN-03

Stick-Type Cleaner 2.5 mm TOOL CLEAN-03

To clean the end face and mating sleeve of a fiber optic connector with 2.5 mm diameter ferrule. SC, FC, ST etc.

TOOL CLEAN-04

Stick-type Cleaner 1.25 mm TOOL CLEAN-04

To clean the end face and mating sleeve of a fiber optic connector with 1.25 mm diameter ferrule, LC, SN etc
