MPO Visual Verifier Test Source KI 28824
The KI 28824 Source is a special purpose visual verification source for multimode and singlemode systems with MPO-12 and MPO-24 connectors. It is usually sold as part of an MPO Visual Verifier Kit. Typical applications of this kit include polarity & continuity checking and endface inspection of MPO-12 and MPO-24 systems.
- Easy to use, rugged
- Long battery life, micro USB power/charger
Use a single tester for: SC, LC, MPO, FC, HFBR, & other connectors - including universal & duplex options.
Smart communication makes sure you always get a full, complete, and consistent test result.
Test tone with multi-fiber ID
Send & identify one of 12 unique test tones. Great for quickly verifying continuity, polarity and rack labelling.
Integrates a VFL into AutoTest, so the fiber end you need to test flashes red. Confidence with a quick & easy visual cue.
Zero warm-up laser (KI2300, KI2400, KI23400 only)
Instant high-accuracy testing. Unlike other sources, Zero Warm-Up sources are in-spec & stabilized in seconds.
Legendary source stability
In real-world field conditions, Kingfisher's stable and accurate sources outshine the competition.
To avoid metal dust fragments damaging your tester and fiber-ends, we use high-end metal-free connectors.
Multimode test standard compliance
Kingfisher LED sources meet Encircled Flux and CPR requirements straight out of the box.
|Output colour||Green, White, Amber|
|Output port||MPO-12, MPO-24|
|MPO capability||4, 8, 12, 24|
|Minimum power per fiber||> -50 dBm|
|Total Emission power (all fibers)||< -20 dBm|
|Fiber type||50/125 µm|
|Connector type||MPO pinned (male) works with both MM/PC & SMF/APC fiber types|
|Distance||1.5 @ MMF, 1 @ SMF|
General KI 2400 & 2800 Handheld Source specifications
|Calibration validity (ISO17025)||3 years|
|Modulated output||270 Hz, 1 kHz, 2 kHz ± 2 %, 12 Multi-Fiber ID tones|
|Autotest (not available for 470, 540 nm LED sources)||Compatible with Kingfisher's 1-way Loss Test Sets & Power Meters (except KI9600, KI23400, KI27400 series)|
|Power||Battery / External power via USB|
|Battery types||2x AA (LR6) Alkaline / 2x AA NiMH AA (rechargeable via USB)|
|Battery life||Laser/LED source: 90/80 hours in Autotest, typical|
|Case||Polycarbonate (body) / rubber (edges & corners), moisture resistance, 1-meter drop tested|
|Size||190 mm x 105 mm x 35 mm|
|Unit weight||0.42 kg|
|Shipping weight||1.5 Kg|
|Operating / storage temperature||-15 to 55 °C / -25 to 70 °C|
|Relative humidity||0 ~ 95 %|
In the box
SC Through Connector OPT046
Canvas Pouch for KI2000 Series Instruments OPT149
Wrist Strap / Lanyard for KI Products
USB Cable (Micro)
Instrument User Manual
Quality Assurance Certificate
Calibration Certificate ILAC/NATA Compliant
Semi-Rigid Carry Case for Test Kits OPT153-CASE
Semi-Rigid Carry Case for Test Kits OPT154B
Hybrid FC Connector Adaptor OPT051
Hybrid Universal 2.5 mm Connector Adaptor OPT081
Hybrid Universal 1.25 mm Connector Adaptor OPT084
Hybrid Universal 1.25 mm Connector Adaptor OPT085
Hybrid LC / F3000 Connector Adaptor OPT072
Hybrid POF Multi-Connector Adaptor OPT077
Hybrid HFBR Connector Adaptor OPT078
